Product Describe：
This product is an integrated navigation signal light control panel specifically designed for vessels, used to centrally manage and operate all types of light signal systems required for marine navigation. Featuring industrial-grade materials and an ergonomic layout, the panel is equipped with multi-channel independent control buttons that support one-touch operation for key lights including portside light, starboard light, masthead light, stern light, etc. It also integrates power management, fault detection, emergency alarm, and other practical functions. Suitable for a wide range of vessels such as merchant ships, fishing boats, and patrol boats, this panel ensures navigational safety and operational convenience.
Product Feature：
Multi-Functional Integrated Design
Supports independent control of navigation lights, all-round lights, masthead lights, stern lights, and other light types, covering all vessel navigation scenarios.
Integrated "TEST" function enables one-touch self-check of all light statuses and circuit continuity for rapid fault diagnosis.
Intelligent Operation Experience
Button layout follows ergonomic principles, with high-contrast silk-screened labels (bilingual Chinese/Spanish) and night-time backlighting for intuitive, easy use.
Equipped with "MUTE" key to temporarily disable alarm sounds; "DIMMER" key to adjust light brightness for varying visibility conditions.
High Reliability and Safety
Seamless switching between main power and auxiliary power ensures continuous operation of critical lights even during power failure.
Panel design with anti-mistouch protection, built-in overload protection and short-circuit protection modules.
Easy Expansion and Maintenance
Modular circuit design supports quick replacement of faulty units; reserved communication interface for integration with the vessel's central control system.
Product Parameters：
Physical Specifications
| Parameter | Details |
|---|---|
| Dimensions | 600mm × 400mm × 80mm (L × W × D; customizable) |
| Material | High-strength AL anodized aluminum |
| Operating Temperature | -20°C ~ +70°C |
Electrical Performance
| Parameter | Details |
|---|---|
| Power Input | Main power: 24V DC / Auxiliary power: 12V DC (dual-power redundant design) |
| Maximum Load | 10A per channel; 80A total load |
| Control Method | Digital signal control; supports brightness adjustment (dimming function) |
Functional Interfaces
| Parameter | Details |
|---|---|
| Light Control Channels | 9 independent outputs (Portside Light, Starboard Light, All-Round White Light, Masthead Light, etc.) |
| Alarm Output | Audible and visual alarm (buzzer + LED indicator) |
Product Picture：
