Product Describe：
The 220V AC Marine Distribution Control Panel is an electrical management system specifically designed for yachts and vessels. It integrates voltage/current display, frequency display, multiple control switches, and indicator lights for managing and monitoring onboard electrical equipment such as shore power, generators, refrigerators, air conditioning pumps, battery chargers, and more. The panel features a modular design for easy installation and maintenance, ensuring safe and efficient operation of the vessel's electrical system.
Product Feature：
Insulation Monitoring
Real‑time monitoring of positive and negative pole insulation to ground, enhancing electrical safety.
Dual‑Battery System Management
Supports automatic/manual switching between service and reserve batteries, ensuring continuous power supply.
Multi‑Circuit Load Di This distribution panel is specifically designed for yachts, operating on a 12V DC supply. It features 3 main power inputs and 19 load outputs, integrating insulation monitoring, current detection, dual‑battery management, and power supply for multiple onboard devices. It is suitable for safe power distribution and control of lighting, navigation, communication, pumps, and other equipment.
stribution
19 independent output circuits covering critical equipment such as navigation, lighting, pumps, and communication devices.
Integrated Instrumentation Display
Intuitive voltage and current readouts for easy monitoring of power status.
Marine‑Specific Design
High protection rating, suitable for humid, vibration‑prone marine environments.
Expandability and Compatibility
Supports connection to common onboard equipment including radar, AIS, GPS, and VHF.
Safety Alarm Functions
Equipped with insulation fault alarms and level alarms to enhance navigational safety.
Product Parameters：
| Power Input | DC voltage: 12V / 24V (exact voltage depends on model specifications) |
| Output Ports | Multiple DC output ports; exact number and current capacity depend on model specifications |
| Control Switches | Various switches for controlling power to different devices |
| Indicator Lights | For displaying equipment status |
| Display Screen | For showing voltage, current, and other parameters |
| Protection Rating | IP65 (exact rating depends on model specifications) |
| Operating Temperature Range | -20°C to +60°C (exact range depends on model specifications) |
| Dimensions | Depending on specific model |
| Weight | Depending on specific model |
Product Picture：
