Product Describe：
This premium marine-grade DC distribution panel is engineered to provide centralized, reliable control over all essential electrical systems aboard your yacht. Designed for the harsh marine environment, this panel consolidates critical functions—from navigation and lighting to bilge pumping and livewell management—into a single, organized helm interface. Each circuit is protected by an independent over-current protection device, ensuring safe and dependable operation. Built with corrosion-resistant materials and precision components, this panel delivers the professional quality and attention to detail demanded by premier yacht builders and discerning boat owners worldwide.
Product Feature：
Comprehensive Circuit Control: Manages a full range of onboard systems including horn, forward and aft bilge pumps, courtesy lights, spreader lights, underwater LEDs, and livewell pump.
Independent Over-Current Protection: Each circuit is equipped with a dedicated circuit breaker or fuse for reliable short-circuit and overload protection.
Dual Bilge Pump Management: Separately controls forward and aft bilge pumps with independent manual override switches. Automatic float switch bypass allows manual activation when needed.
Integrated Lighting Control: Centralized switching for courtesy lights (cockpit illumination), spreader lights (wide-beam deck/work area lighting), and optional underwater LED lights (stern below-waterline illumination).
Livewell System Control: Dedicated switch for activating the livewell pump and light.
Horn Activation: Momentary switch for horn operation meeting USCG sound-signaling requirements.
Marine-Grade Construction: Built with durable, corrosion-resistant materials to withstand saltwater exposure, vibration, and humidity.
LED Status Indicators: Integrated LEDs provide clear visual confirmation of active circuits.
Customizable Configuration: Available with various gang configurations to suit specific vessel requirements.
Product Parameters：
| ominal Voltage | 12V DC / 24V DC (optional) |
| Maximum Total Amperage | 50A – 100A (depending on configuration) |
| Circuit Breaker Type | Magnetic Hydraulic, Trip-Free |
| Branch Circuit Rating | 5A – 15A per circuit (configurable) |
| Panel Material | Heavy-duty 5052-H32 Aluminum Alloy |
| Finish | Two-part polyurethane coating for corrosion resistance |
| Mounting | Surface mount / flush mount |
| Protection Functions | Overcurrent protection, Short-circuit protection |
| Operating Temperature | -25°C to 55°C |
| Relative Humidity | <95% RH, non-condensing |
| Certification | Marine-grade (ABYC / CE compliant) |
Product Picture：
